3 Configuration
3 - 28
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-2-3 Digital CCD Cameras: FZ-S Camera Series
Specification
Model FZ-S FZ-SC FZ-S2M FZ-SC2M FZ-S5M2 FZ-SC5M2
Image ele-
ments
Interline transfer reading all pix-
els, CCD image elements
(1/3-inch equivalent)
Interline transfer reading all pix-
els, CCD image elements
(1/1.8-inch equivalent)
Interline transfer reading all pix-
els, CCD image elements
(2/3-inch equivalent)
Color/Mono
chrome
Monochrome Color Monochrome Color Monochrome Color
Effective
pixels
640 (H) × 480 (V) 1600 (H) × 1200 (V) 2448 (H) × 2044 (V)
Imaging
area H × V
(opposing
corner)
4.8 × 3.6 (6.0 mm) 7.1 × 5.4 (8.9 mm) 8.4 × 7.1 (11 mm)
Pixel size 7.4 (ȝm) × 7.4 (ȝm) 4.4 (ȝm) × 4.4 (ȝm) 3.45 (ȝm) × 3.45 (ȝm)
Shutter
function
Electronic shutter: select shutter speeds from 20 ȝs to 100 ms
Partial
function
12 to 480 lines 12 to 1200 lines 12 to 2044 lines
Frame rate
(Image
Acquisition
Time)
80 fps (12.5 ms) 30 fps (33.3 ms) 16 fps (62.5 ms)
Lens
mounting
C mount
Field of
vision,
installation
distance
Selecting a lens according to the field of vision and installation distance
Ambient
tempera-
ture range
Operating: 0 to 50°C
Storage: -25 to 65°C
(with no icing or condensation)
Operating: 0 to 40°C
Storage: -25 to 65°C
(with no icing or condensation)
Operating: 0 to 40°C
Storage: -25 to 65°C
(with no icing or condensation)
Ambient
humidity
range
Operating and storage: 35% to 85%RH (with no condensation)
Weight Approx. 55 g Approx. 76 g Approx.140 g
Accesso-
ries
Instruction Sheet
