Vision System FH/FZ5 series Hardware Setup Manual (Z366)
Note 1. Site licenses are available for users who will run Sysmac Studio on multiple computers. Ask your OMRON sales
representative for details.
2. Sysmac Studio version 1.07 or higher supports the FH Series. Sysmac Studio does not support the FZ5 Series.
*1. The same media is used for both the Standard Edition and the Vision Edition.
*2. With the Vision Edition, you can use only the setup functions for FH-series/FQ-M-series Vision Sensors.
*3. This product is a license only. You need the Sysmac Studio Standard Edition DVD media to install it.
1-2-6 Software
Product Specifications Model
Number of licenses Media
Sysmac Studio
Standard Edition
Ver.1.
The Sysmac Studio is the software that provides an
integrated environment for setting, programming,
debugging and maintenance of machine automa-
tion controllers including the NJ/NX Series, Ether-
Cat Slave, and the HMI.
Sysmac Studio runs on the following OS.
• OS: Windows XP (Service Pack 3 or higher,
32-bit version) / Windows Vista (32-bit ver-
sion) / Windows 7 (32-bit/64-bit version) /
Windows 8 (32-bit/64-bit version) / Win-
dows 8.1 (32-bit/64-bit version)
--- (Media only)
DVD
*1
SYSMAC-SE200D
1 license --- SYSMAC-SE201L
3 license --- SYSMAC-SE203L
10 license --- SYSMAC-SE210L
30 license --- SYSMAC-SE230L
50 license
---
SYSMAC-SE250L
Sysmac Studio
Vision Edition
Ver.1.
*2*3
Sysmac Studio Vision Edition is a limited license
that provides selected functions required for
FH-series/ FQ-M-series Vision Sensor settings.
1 license
---
SYSMAC-VE001L
Product Specifications Model
Number of Model
Standards licenses
Media
Application Pro-
ducer
Software components that provide a development
environment to further customize the standard con-
troller features of the FH Series.
System requirements:
• CPU: Intel Pentium Processor (SSE2 or higher)
• OS: Windows 7 Professional (32/64bit) or Enter-
prise(32/64bit) or Ultimate (32/64bit),
Windows 8 Pro(32/64bit) or Enterprise(32/64bit),
Windows 8.1 Pro(32/64bit) or Enter-
prise(32/64bit)
• .NET Framework: .NET Framework 3.5 or higher
• Memory: At least 2 GB RAM
Available disk space: At least 2 GB
• Browser: Microsoft Internet Explorer 6.0 or later
• Display: XGA (1024 × 768), True Color (32-bit) or
higher
• Optical drive: CD/DVD drive
• The following software is required to customize
the software:
Microsoft Visual Studio 2010 Professional or
Microsoft Visual Studio 2008 Professional or
Microsoft Visual Studio 2012 Professional
--- (Media only) CD-ROM FH-AP1
1 license
---
FH-AP1L
®
®
®
®
®
®
®
