3-7 LCD and Cable
3
3-7 LCD and Cable
z
LCD Monitor
z
LCD Monitor Cable
Precautions for Correct Use
• Use the DVI-Analog Conversion Cable for Touch Panel Monitor: FH-VMDA when connect the
following Sensor Controllers to the LCD monitor: FZ-M08:
• FH-1000 Sensor Controller
• FH-3000 Sensor Controller
• FH-L Sensor Controller
• FZ-VM cable can use by combining the DVI-I -RGB Conversion Connector: FH-VMRGB.
Specification
Model FZ-M08
Size 8.4 inches
Type Liquid crystal color TFT
Resolution 1,024 × 768 dots
Input signal Analog RGB video input 1 channel
Power supply voltage 21.6 to 26.4 VDC
Current consumption Approx. 0.7 A max.
Ambient temperature range Operating: 0 to 50°C
Storage: -25 to 65°C
(with no icing or condensation)
Ambient humidity range Operating and storage: 35 to 85%RH (with no condensation)
Weight Approx. 1.2 kg
Accessories Instruction Sheet and 4 mounting brackets
Model FZ-VM
Vibration resistiveness 10 to 150 Hz single amplitude 0.15 mm
3 directions, 8 strokes, 4 times
Ambient temperature range Operation: 0 to 50°C
Storage: -20 to 65°C
(with no icing or condensation)
Ambient humidity range Operation and storage: 35 to 85%RH
(with no condensation)
Ambient atmosphere No corrosive gases
Material Cable sheath: heat-resistant PVC Connector: PVC
Minimum bending radius 75 mm
Weight Approx. 170 g
the DVI-Analog Conversion Cable for Touc
h Panel Monitor: FH-VMDA w
the DVI-I -RGB Conversion Connector: FH-VMRGB.
