Instance Name
Functions do not have instance names.
6-1-7
Instructions
Instructions are the smallest unit of the processing elements that are provided by OMRON for use in
POU algorithms.
There are FB instructions and FUN instructions.
Programs and user-defined function blocks consist of a combination of these instructions.
Y
ou can press a shortcut key to display help for an instruction.
Select an instruction that was previously entered in the FBD editor or select an instruction in the In-
struction Navigator in the T
oolbox, and then press the F1 Key.
Additional Information
An instruction refers to a system-defined function or function block.
The following table shows the relationship between user-defined and system-designed func-
tions and the FUN or FB.
User-defined functions System-defined = Instructions
FB
Supported
Supported
FUN Not supported Supported
For details on instructions, refer to the NX-series Safety Control Unit Instructions Reference Manual
(Cat. No. Z931).
Version Information
You can display help with a shortcut key with Sysmac Studio version 1.12 or higher.
6 Programming
6 - 11
NX-series Safety Control Unit User's Manual (Z930)
6-1 POUs (Program Organization Units)
6
6-1-7 Instructions
