A-10
Printing
This section describes how to print information related to Safety Control Unit from the Sysmac Studio.
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for basic printing procedures
for the Sysmac Studio.
A-10-1
Selecting the Items to Print
Use the following procedure to specify Safety Control Unit as the print target.
1 Select File -
Print.
The items that you can print will be displayed.
2 Select the items for the Safety Control Unit.
The Safety Control Unit will be set up for printing.
A-10-2
Items that are Printed
The items that you selected for printing are printed in the order in which the printing items were dis-
played.
Samples of the information that is printed for a Safety Control Unit are provided below.
l
Signature and Validation Boxes
This information is printed on the first page of the Safety Control Unit.
Validation and signature boxes for safety validation are printed.
Appendices
A - 94
NX-series Safety Control Unit User's Manual (Z930)
