Port Data type R/W Name Description Default
Corre-
spond-
ing port
name
IO Power Supply
Error Flag
BOOL R IO Power
Supply Error
Flag
This flag indicates the status of the I/O
power supply voltage.
0: The I/O power supply voltage is nor-
mal.
1: The I/O power supply voltage is in-
correct or the I/O power supply is OFF.
0 ---
Standard Input
2nd Byte
BYTE
R Standard In-
put 2nd Byte
--- 00 hex ---
Si00 Status BOOL R Si00 Status Gives the status of safety input termi-
nal 00.
0: Error
1: No error
0 ---
Si01 Status BOOL R Si01 Status Gives the status of safety input termi-
nal 01.
0: Error
1: No error
0 ---
Si02 Status BOOL R Si02 Status Gives the status of safety input termi-
nal 02.
0: Error
1: No error
0 ---
Si03 Status BOOL R Si03 Status Gives the status of safety input termi-
nal 03.
0: Error
1: No error
0 ---
Si04 Status BOOL R Si04 Status Gives the status of safety input termi-
nal 04.
0: Error
1: No error
0 ---
Si05 Status BOOL R Si05 Status Gives the status of safety input termi-
nal 05.
0: Error
1: No error
0 ---
Si06 Status BOOL R Si06 Status Gives the status of safety input termi-
nal 06.
0: Error
1: No error
0 ---
Si07 Status BOOL R Si07 Status Gives the status of safety input termi-
nal 07.
0: Error
1: No error
0 ---
A-6-3
NX-SOH200 Safety Output Unit
Port Data type R/W Name Description Default
Corre-
spond-
ing port
name
Standard Input
1st Byte
BYTE R Standard In-
put 1st Byte
--- 00 hex ---
Appendices
A - 77
NX-series Safety Control Unit User's Manual (Z930)
A-6 I/O Ports of Safety I/O Units
A
A-6-3 NX-SOH200 Safety Output Unit
