A-6-2
NX-SID800 Safety Input Unit
Port Data type R/W Name Description Default
Corre-
spond-
ing port
name
Standard Input
1st Word
WORD
R Standard In-
put 1st Word
--- 0000 hex ---
Si00 Logical Val-
ue
BOOL R Si00 Logical
Value
Gives the status of safety input termi-
nal Si00.
0: OFF, 1: ON
0 Same
Si01 Logical V
al-
ue
BOOL R Si01 Logical
Value
Gives the status of safety input termi-
nal Si01.
0: OFF, 1: ON
0 Same
Si02 Logical V
al-
ue
BOOL R Si02 Logical
Value
Gives the status of safety input termi-
nal Si02.
0: OFF, 1: ON
0 Same
Si03 Logical V
al-
ue
BOOL R Si03 Logical
Value
Gives the status of safety input termi-
nal Si03.
0: OFF, 1: ON
0 Same
Si04 Logical V
al-
ue
BOOL R Si04 Logical
Value
Gives the status of safety input termi-
nal Si04.
0: OFF, 1: ON
0 Same
Si05 Logical V
al-
ue
BOOL R Si05 Logical
Value
Gives the status of safety input termi-
nal Si05.
0: OFF, 1: ON
0 Same
Si06 Logical V
al-
ue
BOOL R Si06 Logical
Value
Gives the status of safety input termi-
nal Si06.
0: OFF, 1: ON
0 Same
Si07 Logical V
al-
ue
BOOL R Si07 Logical
Value
Gives the status of safety input termi-
nal Si07.
0: OFF, 1: ON
0 Same
Safety Connec-
tion Status
BOOL
R Safety Con-
nection Sta-
tus
This flag indicates when a safety con-
nection is active. Use it for an input to
the Activate terminal on a safety FB or
for safety connection/disconnection
applications.
0 Same
Safety Input Ter-
minal Status
BOOL R Safety Input
Terminal Sta-
tus
This flag indicates the status of the
safety input terminals.
0: An error has occurred on one of the
safety input terminals.
1: All of the safety input terminals are
normal (no errors).
0 Same
Unit Normal Sta-
tus
BOOL
R Unit Normal
Status
This flag indicates the status of the
Unit.
0: An error has occurred.
1: Normal (no errors)
0 ---
Appendices
A - 76
NX-series Safety Control Unit User's Manual (Z930)
