2-177
2-8 Parameter Unit and Cable Specifications
All dimensions are in millimeters unless otherwise specified.
2-8-1 Parameter Unit
H R88A-PR02W Hand-held Parameter Unit
Parameter Units are required for operation and monitoring the Servo
Driver at a remote location or with a control panel.
Note A 1-meter cable is provided with the Parameter Unit. If this is not
long enough to connect between the Parameter Unit and the
Servo Driver, then use the R88A-CCW002C Parameter Unit
Cable (2 meters, purchased separately).
H General Specifications
Item Standards
Operating ambient temperature 0 to 55°C
Storage ambient temperature –10 to 75°C
Operating ambient humidity 35% to 85% (with no condensation)
Storage ambient humidity 35% to 85% (with no condensation)
Storage and operating
atmosphere
No corrosive gasses.
Vibration resistance 4.9 m/s
2
max.
Impact resistance Acceleration 19.6 m/s
2
max.
Standard Models and Specifications Chapter 2
