Master gain (M.GAIN)
Displaying and setting the master gain (M.GAIN)
The adjustment value of the master gain (M.GAIN) is displayed on the [M.GAIN] display (B).
When the setting value is changed from the standard position set in the ROP menu, the [M.GAIN] indicator (A) is orange lit. (The standard
position remains set while the indicator is green lit.)
“STD POSITION M.GAIN” (see page 112)
A. [M.GAIN] indicator
B. [M.GAIN] display
C. [M.GAIN] setting buttons
D. [VAR] button
Operating procedure
1. Press the [M.GAIN] setting buttons (C)
This allows you to change the master gain setting value.
When the [VAR] button (D) is pressed to turn on the button, the master gain can make fine adjustments. (Range of ±2.9
in 0.1 dB steps)
- 42 -
Adjustment and settings
