03 BLACK SHADING
The setting values will vary depending on the connected camera.
ンヨ
ンヨ
ャ
ャ
ラチヱモンモ
ンヨャ
ラチヴモヸ
ヷチヴモヸ
ャロモヤレチヴラモュリワヨ
ヒチバチビ
パパパ
パパパ
パパパ
ヰワ
ンヨャ
ヷチヱモンモ
ャロモヤレチヴラモュリワヨ
ビチバチビ
パパパ
ヤヰンンユヤヵ
ヰワ
ヰワ
Item Setting details
H SAW R Adjusts the black shading gain for R, G, and Bch in the horizontal direction using a sawtooth waveform.
H SAW G
H SAW B
H PARA R Adjusts the black shading gain for R, G, and Bch in the horizontal direction using a parabolic waveform.
H PARA G
H PARA B
V SAW R Adjusts the black shading gain for R, G, and Bch in the vertical direction using a sawtooth waveform.
V SAW G
V SAW B
V PARA R Adjusts the black shading gain for R, G, and Bch in the vertical direction using a parabolic waveform.
V PARA G
V PARA B
CORRECT Enables or disables black shading (sawtooth waveform or parabolic waveform) correction.
- 69 -
