Display Item
SCENE
Displays the currently set scene number.
“Scene file” (see page 37)
ND
Displays the ND filter name acquired from the CCU.
“ND filter” (see page 39)
CC
Displays the CC filter name acquired from the CCU.
“CC filter” (see page 40)
ECC
Displays the current information of [09 ECC] > [COLOR TEMP] in the ROP menu.
“Color temperature (ECC)” (see page 41)
SHT
Displays the currently set shutter value.
“Shutter (SHUTTER)” (see page 43)
ASSIGN
This displays the ASSIGN information.
ンヨ
ンヨ
ャ
ャ
ヨモリワラュチチュヵロ
パパパ
ピビパパ
パ
パパパ
ョヘチハチブ
ョロモンユヵユヮヱ
ュンヴチホチヰョョヨバロチホチリワヵ
ヤパ
ヮモヵンリヹヤハチヵユヮヱ
ラュチハチュレワユユヨモヮヮモ
ヒバビ
Display Item
G/L
The status of the GENLOCK is displayed here.
NG: UNLOCK
EXT: Externally synced
INT: Internally synced
DRS
Displays the current information of [01 PAINT SWITCH] > [DRS] in the ROP menu.
“DRS” (see page 67)
- 51 -
Status screen
