4.30
ELECTRONIC FUEL INJECTION
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
TPS Adjustment Using Digital Wrench™:
1. Assemble Sma rtLink M odule a nd co nnect the
d
iagnostic interface ca ble to the veh icle to allo w
Digital W rench™ us e (see “Digital Wrench™ -
Diagnostic Connector”).
2. Select the appropriate ve hicle an d op en the da ta
dis
play grid. C lick on the meter ic on next to “TPS
Volts”.
3. Loosen the TPS mounting screws.
4. Rotate the TPS un til your d isplay r eading is within
s
pecification.
5. Retighten the TPS mo unting scre ws a nd torque to
s
pecification.
6. Verify volta ge reading did n ot cha nge. If voltage
rea
ding is now out of specification, repeat steps 3 - 5.
7. Reinstall item s that wer e r emoved to access TPS
se
nsor.
TPS Output Reading (Digital Wrench™):
0.46 ± 0.03 Vdc
= T
TPS Mounting Screws:
17.7 in. lbs. (2 Nm)
