8.7
TRANSMISSION
8
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
18. Remove the (4 ) fasteners se curing the r ear b olt in
brace to the vehicle main frame. Maneuver the brace
forward for transmission removal clearance. Note the
routing of the tra nsmission b reather ho se an d wire
harness.
19. Remove the clip and washer (D) secur ing the shift
cab
le to the bell crank.
20. Remove the (2) fasteners securing the transmission
shift br
acket (E) to the transmission case. Swing
assembly cle ar of the main fr ame for tr ansmission
removal.
21. Disconnect the ve hicle spe ed sen sor ( F) and ge ar
p
osition switch (G) harness connectors. Cut tie strap
(H). Note harness routings for reassembly.
22. Remove the transmission vent tube (I). 
INTL - Remo
ve the parking break cable and asm.
23. Remove and discar d the ( 4) rear br ake ca liper
m
ounting bolts on the RH and LH side as outlined in
Chapter 7 and 9.
CAUTION: Do no
t hang the caliper by the brake line.
Use wir e to hang calip er to p revent da mage to the
brake line.
24. Remove the (4) rear upper and lower A-arm to bearing
ca
rrier bolts, nuts and washers from the RH and LH
side as outlined in chapter 7.
25. With a short, sharp jerk, remove the rear drive shaft /
b
earing carrier assemblies from the vehicle as shown.
26. Remove the (2) bolts securing the starter motor to the
e
ngine. Remove starter from the engine. Make note
of wiring for reassembly.
27. Place a support in-between the main frame and the
e
ngine crankcase to support the engine in its current
position. Do not pinch brake line.
E
D
F
G
H
I
