3.32
ENGINE / COOLING SYSTEM
9923523 - 2012 RANGER RZR 570 Service Manual
© Copyright 2011 Polaris Sales Inc.
7. In seq uence, to rque the (8 ) e ngine cou pler br acket
fasteners to specification.
8. In a criss-cross pattern, to
rque the (4 ) fro nt eng ine
mount fasteners to specification.
9. Torque th e (2) front center iso lator bolts to
spec
ification.
10. Remove the lifting straps and overhead or portable
eng
ine hoist an d r emove th e sup port pr eviously
installed under the tra nsmission case du ring th e
engine removal process.
11. Reposition th e e xhaust system a nd insta ll the (3)
rub
ber exhaust hangers, new exhaust seal and the (3)
head p ipe bo lts. To rque he ad pipe b olts to
specification.
12. Install the (3) coolant hoses onto the engine.
13. Install the throttle body and air box. Tighten the hose
cla
mps that secure the throttle body to the intake boot
and air box.
14. Install the lower stater motor
bolt through the lower
starter motor mounting boss.
15. Instal the starter motor onto the engine.
16. Install the starter motor and ba
ttery cables as outlined
in Chapter 10.
= T
Rear Engine Coupler Fastener (In Sequence):
55 ft. lbs. (74.5 Nm)
= T
Front Engine Mount Fasteners:
40 ft. lbs. (54 Nm)
= T
Isolator Center Bolt:
40 ft. lbs. (54 Nm)
55 ft. lbs
(74.5 Nm)
40 ft. lbs.
(54 Nm)
40 ft. lbs.
(54 Nm)
= T
Exhaust Head Pipe Bolts:
18 ft. lbs. (24.5 Nm)
= T
Starter Motor Fastener:
7 ft. lbs. (10 Nm)
New
18 ft. lbs.
(24.5 Nm)
