4. Device type and user-board explanation
4.1. Device type explanation:
Explanation of device type:
RC3000-XXX-XX-XX AC
There are 4 types of line-boards of RC3000:
RC3000-OPT-2E1 RC3000 line-board of optical interface
RC3000-OPT-FE RC3000 line-board of optical interface
RC3000-4E1 RC3000 line-board of 4 E1 interfaces
RC3000-2E1 RC3000 line-board of 2 E1 interfaces
RC3000-2E1 (ADM) RC3000 line-board of 2 E1 interfaces
RC3000-OPT-FE line-board has an optical interface and a 100M Ethernet interface;
RC3000-OPT-2E1 line-board has an optical interface and 2 E1 ports; RC3000-4E1
line-board has 4 balanced E1 interface; RC3000-2E1 and RC3000-2E1 (ADM) have two
CC3 (coaxial cable 3) E1 interfaces, and RC3000-2E1 (ADM) function.
For RC3000-OPT the optical module type decides the device type as following table:
Device type Optical module type
RC3000-OPT-S1 Single-mode Dual-fiber 1310, DSC, 0~25Km
RC3000-OPT-S2 Single-mode Dual-fiber1310, DSC, 10~60Km
RC3000-OPT-S3 Single-mode Dual-fiber 1550, DSC, 15~120Km
RC3000-OPT-SS13 Single-mode Single -fiber Dual-wavelength T1310/R1550, SC,
0~25Km
RC3000-OPT-SS15 Single-mode Single -fiber Dual-wavelength T1550/R1310, SC,
0~25Km
RC3000-OPT-SS23 Single-mode Single -fiber Dual-wavelength T1310/R1550, SC,
10~50Km
RC3000-OPT-SS25 Single-mode Single-fiber Dual-wavelength T1550/R1310, SC,
10~50Km
Device name: multi-service multiplexer
Line-board
Optical interface type of optical line-board
Power supply type: AC or DC
Assistant interface type of optical line-board
