Prepare the Media
2
Basic
Operation
31
Usable Media
This machine cannot necessarily print every kind of media. When selecting media, be sure to carry out testing
in advance to make sure that satisfactory printing quality is obtained.
Size
Width (For both Roll Media and sheet media)
259 to 1,625 mm (10.2 to 64 inches)
Maximum media thickness (For both Roll Media and sheet media)
1.0 mm (39mil)
Roll outer diameter
210 mm (8.3 inches)
Paper tube (core) inner diameter
76.2 mm (3 inches) or 50.8 mm (2 inches)
Note: To use 2 inches media, the optional media anges are required. For information about optional items,
contact your authorized dealer or us.
Roll weight
40 kg (88 lb.)
Note: When using the take-up unit, conditions are dependent on the usable media of the take-up unit.
Other conditions
Media such as the following cannot be used.
Media whose end is attached to the paper tube (core)
Media which is severely warped or which has a strong tendency to reroll
Media that cannot withstand the heat of the media heating system
Media whose paper tube (core) is bent or crushed
Media that bends under its own weight when loaded
Media on a sagging roll
Media that is rolled unevenly
