3
Maintenance
Replacing Consumable Parts
77
Replacing the Felt Wiper
The felt wiper is a component that you use when cleaning the print head. When the screen displays a message
like the one shown, it means the item needs to be replaced. Replace with new items.
Regarding the purchase of the felt wiper, contact your authorized Roland DG Corp. dealer.
CAUTION
Be sure to perform operations as specied by these instructions, and
never touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
1.
Enter the felt wiper replacement menu.
When the message shown in the gure appears, press
.
Remove any media.
Press .
Press several times until the screen shown on
the left appears.
Press
, and then .
Press .
Press
twice.
Press .
The print-head carriage moves to a location where felt wiper replace-
ment is possible, and then the screen shown in the gure appears.
Remove the cover R.
TIME FOR
FELT REPLACE
TIME FOR
FELT REPLACE
MAINTENANCE
REPLACE FELT
OPEN COVER R
Screws
Cover R
Hook
To Next Page
