3
Maintenance
Replacing Consumable Parts
80
Replacing the Separating Knife
If the separating knife becomes dull, replace it with the included replacement knife.
CAUTION
Be sure to perform operations as specied by these instructions, and
never touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
CAUTION
Never touch the tip of the blade with your ngers.
Doing so may result in injury.
1.
Replacing the Separating Knife
Remove any media.
Press .
Press several times until the screen shown on
the left appears.
Press
, and then .
Press .
Press several times to display the screen shown
on the left.
Press
.
The carriage moves to the position where the knife can be replaced,
and the screen shown in the gure appears.
Open the front cover.
Preparations are complete when this screen appears.
2.
Replace the separating knife
Remove the separating knife.
Loosen the screw until it slips out.
Grasp the screw portion, and slowly pull
it out in the direction of the arrow. When
doing this, do not pull it back toward you.
①
②
②
