Operating manual  VISATRON® Oil Mist Detector  VN2020 / VN2020 EX

Part number 183001  Version 3.0

ASSEMBLY AND INSTALLATION

 Press the flexible hose [] onto the opening (test mist inlet) of the previously

removed screw plugs of the siphon blocks, as shown, or onto the open end of

the header pipe.

 Then carry out steps 1-5 (measurement) in this section.

 Finally, remove the flexible hose again and then close the siphon block with the

screw plug [] or tighten it hand-tight:

Factory test with smoke generator (steps 1-3)

1: Siphon block

2: Screw plug

 The VISATRON

VN2020 oil mist detector is now ready for

operation!
