Operating manual  VISATRON® Oil Mist Detector  VN2020 / VN2020 EX
Part number 183001  Version 3.0
81
ASSEMBLY AND INSTALLATION
Recommended electrical installation, terminal box for VN2020
1: Terminal box, VN2020
2: Recommended electrical installation with cable ties
1
AF size 24
AF size 27
