Operating manual  VISATRON® Oil Mist Detector  VN2020 / VN2020 EX

Part number 183001  Version 3.0

149

MAINTENANCE AND REPAIR

1: Screw plug (new)

Replacing the screw plug on the VN2020 measuring head (steps 1-3)

1: Inspection cover

3: Allen key, size 6

2: Screw plug (old)

(Torque spanner for 15 Nm)

 Finally, screw the screw plug [] into the inspection cover to a torque of

15 Nm.

 The screw plug on the inspection cover has been successfully

replaced and the device is ready for operation!
