Operating manual  VISATRON® Oil Mist Detector  VN2020 / VN2020 EX

Part number 183001  Version 3.0

ASSEMBLY AND INSTALLATION

1: U-tube manometer

2: Quick-release coupling

Setting the neg. pressure on the VN2020 / VN2020 EX measuring head (steps 1-6)

1: Pressure regulator unit

3: U-tube manometer

2: Adjusting cap

Once the preparatory work has been successfully completed in accordance with the

above installation steps 1-5, the other settings are changed on device in accordance

with Figure 53 (installation step 6):

1. The allowed negative pressure on the VISATRON® VN2020 / VN2020 EX is set using

the pressure regulator unit [] and the supplied U-tube manometer []. (Accessories)

60 mmWC

 5 mmWC
