Siemens SIMATIC MOBY D User Manual

MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
149
Write/read devices with RS232 interface
6
6.1 Overview of SLG with RS 232 serial interface
6\VWHPLQWHUQDO56LQWHUIDFH
3&LQWHUIDFH
56
0':$3,
6/*' 6/*'6/*'
$17'
$17'
$17'
$17'
Figure 6-1 Write/read devices with RS232 interface
Application area
The SLG with the serial RS 232 interface provides the communications interface between
almost any higher-level computer systems, PCs and the mobile data storage unit (MDS).
