MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
205
Antennas
8
8.1 ANT D2
8.1.1 Features
ANT D2 Features
Applications Suitable for high speeds, e.g. in
 Overhead conveyors
 Assembly lines
 Production
 Order picking
Antenna field Designed for transponders that are directed
sideways past the antenna.
See Chapter Transmission window (Page 207)
Writing/reading distance typ. 60 mm;
Connecting cable 3.3 m (included in scope of supply)
Connectable SLGs
 SLG D11
 SLG D11S
Degree of protection IP65
8.1.2 Ordering data
Table 8- 1 ANT D2 ordering data
Product Order No.
ANT D2
incl. antenna cable (3.3 m)
6GT2698-5BB00
Table 8- 2 Ordering data for ANTD2 accessories
Accessories Order No.
Antenna duplexer
(with 1 antenna connecting cable 3.3 m)
6GT2690-0AC00
Antenna cable, length 10.5 m 6GT2691-0CN10
Antenna extension, length 7.2 m 6GT2691-0DH72
