Siemens SIMATIC MOBY D User Manual

Write/read devices with RS422 interface
7.2 SLG D10S basic unit
MOBY D
176 System Manual, 01/2010, J31069-D0147-A6-7618
7.2.3 Technical data
Table 7- 4 Technical data for SLG D10S basic unit
Inductive interface to the MDS
Transmission frequency 13.56 MHz
Transponders supported Transponders according to ISO 15693 and I-
Code1
Serial interface to the user RS 422
Transmission protocol Asynchronous 8 bit
Data transmission rate 19.2 Kbaud to 115.2 Kbaud
(depending on ASM)
Data backup CRC 16
Transmit power up to 10 W
Write/read distances for SLG 650 mm typically (see field data)
Software functions Read, write, initialize MDS
The Repeat command is not permissible.
A buffer of up to 256 bytes is available in the SLG
for concatenating commands For one command,
therefore, it is only possible to combine
commands until the sum of the header and user
data of the individual message frames does not
exceed this value. FC 45 limits the user data
length for each individual message frame to 233
bytes.
Programming FC 45
Transmission protocol 3964R
Multitag Available soon
Power supply
'&9s
Current consumption
 Operation
 Inrush current, momentary
 up to 1.4 A
 2.8 A/50 ms
Cable length for SLG S7
 With RS 422  300 m
Digital inputs/outputs None
Enclosure dimensions (L x W x H) in mm 320 x 145 x 100 (without connector)
Color Anthracite
Material Aluminum
Connector
 Antenna (plugs into SLG)
 RS 422 interface
 Power supply
 TNC connector
 9-pin Sub-D connector (male)
 4-pin M12 connector (male)
SLG fixing 4 x M6 screws
