Previous versions
C.2 Discontinued SLG with ANT D5
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
333
Note
In order to guarantee optimum field data even in the vicinity of metal, ANT D5 is calibrated at
the factory at a distance of 100 mm from metal.
Spacer kit for MOBY D ANT D5
See the Section
Write/read devices, SLG D10 basic unit
C.2.5 SLG D11S ANT D5 (6GT2602-0AC00)
Application area
SLG D11S ANT D5 is a write/read device in the mid performance range with a serial
interface and a separate antenna which has been specially designed for warehouses,
logistics and distribution. It is designed for a range of up to 380 mm (depending on the label).
The write/read device is equipped with a serial RS 422 interface that supports
communication to SIMATIC S7 or PROFIBUS DP-V1 through the interface modules
(ASM 452, ASM 456, ASM 473 and ASM 475).
FC 45 is one method of quick and easy programming available to the user. The rugged
housing and high degree of protection (IP65) permit use even under the toughest industrial
conditions.
Figure C-23 Write/read device SLG D11S ANT D5
