Siemens SIMATIC MOBY D User Manual

Write/read devices with RS422 interface
7.5 SLG D12S (plug-in version)
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
197
Weight, approx. 600 g
Approvals
 CE
 Harmless to heart pacemakers
7.5.4 Field data
Table 7- 14 Field data for SLG D12S special version
Limit distance (S
g
) max. 160 mm (dependent on transponder)
Operating distance (S
a
) 0 to 120 mm (dependent on transponder)
Length of transmission window (L
x
/L
y
) 120 mm/60 mm
Width of the transmission window (W
x
/W
y
) 48 mm/24 mm
Minimum distance from SLG D12S to SLG D12S ≥ 0.5 m
See also MOBY D System Manual, Chapter .
