6.3 SLG D11 basic unit
MOBY D
158 System Manual, 01/2010, J31069-D0147-A6-7618
6.3.3 Technical specifications
Table 6- 8 Technical data of SLG D11
Inductive interface to the MDS
Transmission frequency 13.56 MHz
Transponders supported Transponders to ISO 15693 and I-Code1
Serial interface to the user RS 232
Transmission protocol Asynchronous 8 bit
Data transmission rate 9600 baud to 38.4 Kbaud (adjustable)
Data backup CRC 16
Transmit power 1 W
Write/read distances
SLG - MDS
See
Software functions Read, write, initialize MDS, access rights
Programming Windows 9x, 2000, NT and XP,
with 32 bit DLL available
Multitag Yes
Anti-collision speed approx. 20 labels/s simultaneously identifiable
Power supply
 Rated value
 Permitted range

'&9

'&9s8/RQO
\
'&99
Current consumption
 Operation
 Inrush current, momentary
 200 mA
 600 mA
Cable length, SLG - PC
 With RS 232  Max. 30 m
Digital inputs/outputs None
Dimensions (L x W x H) in mm 160 x 80 x 40 without connector
Color Anthracite
Material Plastic PA 12
Connectors
 Antenna (plugs into SLG)
 V24 interface
 Power supply
 TNC connector
 9-pin Sub-D connector (male)
 4-pin M12 connector (male)
SLG fixing 2 x M5 screws
Tightening torque
(at room temperature)
≤ 2 Nm
Ambient temperature
 Operation
 Transport and storage
 -25 °C to +55 °C
 -25 °C to +70 °C
MTBF 2.0 x 10
5
hours
Degree of protection to EN 60529 IP65 (UL: for indoor only)
