Accessories
10.3 MOBY antenna distributor
MOBY D
278 System Manual, 01/2010, J31069-D0147-A6-7618
Technical data
Table 10- 9 Technical data for MOBY D antenna distributor
Max. input power 10 W
Transmission frequency 13.56 MHz
Power supply None
Enclosure dimensions (L x W x H) in mm 160 x 80 x 40 (without connector)
Color Anthracite
Material Plastic PA 12
Connector (inputs and outputs) TNC connector
Mounting 2 x M5 screws
Ambient temperature
ï‚· Operation
ï‚· Transport and storage
 -25 °C to +65 °C
 -25 °C to +75 °C
MTBF 3.0 x 10
5
hours
Degree of protection according to EN 60529 IP65 (UL: for indoor use only)
Shock resistant according to EN 60721-3-7 Class 7M2
Total shock response spectrum Type II
30 g
Vibration according to EN 60721-3-7 Class 7M2 1 g (9 to 200 Hz)/
1.5 g (200 to 500 Hz)
Weight, approx. 400 g
Approval CE
UL
