C.2 Discontinued SLG with ANT D5
MOBY D
320 System Manual, 01/2010, J31069-D0147-A6-7618
Technical data
Table C- 11 Technical data for SLG D11 ANT D5
Inductive interface to the MDS
Transmission frequency 13.56 MHz
Transponders supported Transponders to ISO 15693 and I-Code1
Serial interface to the user RS 232
Transmission protocol Asynchronous 8 bit
Data transmission rate 9600 baud to 38.4 Kbaud (adjustable)
Data backup CRC 16
Transmit power 1 W
Write/read distances
SLG - MDS
380 mm typically (see field data)
1
Software functions Read, write, initialize MDS, access rights, multitag
Programming Windows 9x, 2000, NT and XP,
with 32 bit DLL available
Multitag Yes
Anti-collision speed approx. 20 labels/s simultaneously identifiable
Power supply
 Rated value
 Permitted range

'&9

'&9s8/RQO\
'&99
Current consumption
 Operation
 Inrush current, momentary
 150 mA
 600 mA
Cable length, SLG - PC
 With RS 232  30 m
Antenna cable length 3.60 m
Digital inputs/outputs None
Dimensions (L x W x H) in mm
 For antenna
 For the electronics
 340 x 325 x 38
 160 x 80 x 40 without connector
Color
 Antenna
 SLG housing
 Black
 Anthracite
Material
 Antenna
 SLG housing
 Plastic ASA
 Plastic PA 12
Connectors
 Antenna (plugs into SLG)
 V24 interface
 Power Supply
 TNC connector
 9-pin Sub-D connector (male)
 4-pin M12 connector (male)
SLG fixing 2 x M5 screws
