03.2010 Parameterization
Siemens AG 6SE7087-6QX70 (Version AL)
SIMOVERT MASTERDRIVES Compendium Motion Control 5-21
5.4.3.6 OP: Download
With the "OP: Download" function, a parameter set stored in the OP1S
can be written into the connected slave. Starting from the basic menu,
the "OP: Download" function is selected with "Lower" or "Raise" and
activated with "P".
Download
*1909199701
MASTERDRIVES MC
P
MotionControl
*Menu selection
OP: Upread
#OP: Download
Example: Selecting and activating the "Download" function
One of the parameter sets stored in the OP1S must now be selected
with "Lower" or "Raise" (displayed in the second line). The selected ID
is confirmed with "P". The slave ID can now be displayed with "Lower"
or "Raise" (see section "Slave ID"). The "Download" procedure is then
started with "P". During download, the OP1S displays the currently
written parameter.
Download
*1909199701
MASTERDRIVES MC
P
Download
*1909199701
MASTERDRIVES MC
MotionControl 00
Download
Pxxx
P
Example: Confirming the ID and starting the "Download" procedure
With "Reset", the procedure can be stopped at any time. If downloading
has been fully completed, the message "Download ok" appears and the
display returns to the basic menu.
After the data set to be downloaded has been selected, if the
identification of the stored software version does not agree with the
software version of the unit, an error message appears for
approximately 2 seconds. The operator is then asked whether
downloading is to be discontinued.
Download
*1909199701
MASTERDRIVES MC
P
Download
*1909199701
MASTERDRIVES MC
Error:
Different
IDs
P
MotionControl 00
Stop download?
#yes
no
2 s
Yes: The "Download" procedure is discontinued.
No: The "Download" procedure is carried out.
