09.2008 Communication / PROFIBUS
Siemens AG 6SE7087-6QX70 (Version AK)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-57
8.2.7 Starting up the CBP
With regard to basic parameterization, please note the differences to the
types of unit with the older function classes FC (CU1), VC (CU2) and SC
(CU3). These differences are described below.
In order to make these differences clear, these parameter numbers and
other deviations are either printed in dark gray or have a dark-gray
background.
8.2.7.1 Basic parameterization
For the CBP optional board, it is not necessary to adjust the baud rate.
Optional boards?
P060 = 4
P711.1 = x
no
yes
Possible optional boards: CBP, TB
Function selection "Hardware configuration"
Optional for start-up diagnosis
P712.1 =
2...5
Optional; if PPO type cannot be set via
PROFIBUS-DP master
P713.1 =
.
P721.1 =
Reserved
.
Reserved
P918.1 = n
CBP bus address 0 < n < 126
P060 = 1
Leave "Hardware configuration"
P053 = x
P060 = 5
Parameter access CBP
Function selection "Drive setting"
Fig. 8.2-18 Parameterization of "Hardware configuration" for CUPM, CUMC, CUVC
and Compact Plus
With MASTERDRIVES Performance 2, the CB parameters P918 and
P711 to P721 can also be changed in the "Drive setting" state (P60 = 5).
In the case of MASTERDRIVES MC (CUMC) and MC+ (Compact+) from
firmware version V1.4 onwards, the CB parameters P918 and P711 to
P721 can also be changed in the "Drive setting" status (P060 = 5).
NOTE
NOTE
Basic
parameterization
with CUPM, CUMC,
CUVC and Compact
PLUS
