SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-35
8.2.4.7 Example of "Change parameter value", multi-parameter
Parameter task:
Offset
Task header Task reference
Task identifier =
Change parameter
0
Axis = 0 No. of parameters = 3 2
1
st
parameter address Attribute = value No. of elements = 1 4
Parameter number
Subindex = 7
2
nd
parameter
address
Attribute = value No. of elements = 100 10
Parameter number
Subindex = 0
3
rd
parameter address Attribute = value No. of elements = 2 16
Parameter number
Subindex = 0
1
st
parameter value(s) Format = word No. of values = 1 22
Value 24
2
nd
parameter
value(s)
Format = word No. of values = 100 26
Value 1 28
Value 2
...
Value 100
3
rd
parameter value(s)
Format = double
word
No. of values = 2 228
Value1 230
Value2
238
Parameter response (+): All part access o.k.
Response header Task ref. mirrored
Response identifier =
Change parameter (+)
0
Axis mirrored No. of parameters = 3 2
4
