– Secure plug connections -2- and -6- with screws M5 -D- at
slide valve body.
Note
♦ If the cable -3- (for gearbox input rpm sender - G182- ) is too
short, in order to screw the plug connection -2- on the provided
point onto the slide valve body, it was wrongly routed or trap‐
ped by the slide valve body, then the slide valve body must be
removed again and the cable must be correctly routed.
♦ Trapped cables must be replaced.
– Hang the wiring harness -B- in the bracket -C- and route in the
same way according to the illustration.
– Install oil filter
⇒ “1.5 Removing and installing the oil filter”, page 170 .
– Installing the oil pan ⇒ page 169 .
– Top up with ATF and inspect ATF level ⇒ “4 ATF”, page 147 .
Tightening torques
Component Nm
Slide valve body to gearbox housing (from out‐
side to the inside)
M6 screws, pay attention to different screw
lengths
1)
⇒ “1.2 Summary of components - oil pan, oil strainer, slide
valve body, internal wiring looms”, page 165
Gearshift lever on gearshift shaft (nut) ⇒ “1.2 Summary of components - oil pan, oil strainer, slide
valve body, internal wiring looms”, page 165
Gearbox oil temperature sender - G93-
(M6 screw with bracket to slide valve body)
⇒ “1.2 Summary of components - oil pan, oil strainer, slide
valve body, internal wiring looms”, page 165
2 x plug for the speed sender
(M5 screw with bracket to slide valve body)
⇒ “1.2 Summary of components - oil pan, oil strainer, slide
valve body, internal wiring looms”, page 165
1)
Replace bolts.
1.7 removing and installing wiring loom with
14-pin plug
Note
⇒ “2 Information and repair instructions for the automatic gearbox
09G”, page 12 .
WARNING
Observe measures when disconnecting and connecting the
battery ⇒ Electrical System; Rep. gr. 27 .
Removing
– Disconnect the battery-earth strap with the ignition off ⇒ Elec‐
trical System; Rep. gr. 27 .
– Removing the oil pan
⇒ “1.4 Removing and installing oil pan”, page 168 .
Fabia II 2007 ➤ , Fabia II 2009 ➤ , Fabia II 2011 ➤ , Octavia II 2004 ➤ ...
Gearbox 09G - Edition 07.2014
180 Rep. gr.38 - Gears, control
