2 Removing, installing and setting mul‐
ti-function switch - F125-
⇒ “2.1 Removing and installing the multi-function switch F125 ”,
page 185
⇒ “2.2 Setting multi-function switch F125 ”, page 187
2.1 Removing and installing the multi-func‐
tion switch - F125-
Removing
– Shift selector lever to position “N”.
– Switch off ignition.
– Remove air filter ⇒ Engine; Rep. gr. 24 .
– Lever off the selector lever control cable -1- from the gearshift
lever -6-, e.g using an open-end wrench, while ensuring that
the selector lever control cable does not get kinked.
Note
Do not release screw -2-.
– Unplug connector -5- at multi-function switch.
– Remove gearshift lever -1-.
Fabia II 2007 ➤ , Fabia II 2009 ➤ , Fabia II 2011 ➤ , Octavia II 2004 ➤ ...
Gearbox 09G - Edition 07.2014
2. Removing, installing and setting multi-function switch F125 185
