1.10 Removing and installing the gearbox
output r.p.m. sender - G195-
Note
⇒ “2 Information and repair instructions for the automatic gearbox
09G”, page 12 .
WARNING
Observe measures when disconnecting and connecting the
battery ⇒ Electrical System; Rep. gr. 27 .
Removing
– Disconnect the battery-earth strap with the ignition off ⇒ Elec‐
trical System; Rep. gr. 27 .
– Removing the oil pan
⇒ “1.4 Removing and installing oil pan”, page 168 .
– Removing oil filter
⇒ “1.5 Removing and installing the oil filter”, page 170 .
– Remove the slide valve body
⇒ “1.6 Removing and installing the slide valve body”,
page 171 .
– Release screw -2-.
– Pull gearbox output r.p.m. sender - G195- with cable -B- out
of the gearbox.
Install
Installation is performed in the reverse order, pay attention to the
following points:
– Moisten O-ring at sender with ATF.
– Carefully press gearbox output r.p.m. sende - G195- up to the
stop into the gearbox.
Tightening torque
Component Nm
Gearbox input r.p.m. sender - G195- to
gearbox, M5 screw
⇒ “1.2 Summary of components - oil pan, oil strainer, slide valve
body, internal wiring looms”, page 165
Fabia II 2007 ➤ , Fabia II 2009 ➤ , Fabia II 2011 ➤ , Octavia II 2004 ➤ ...
Gearbox 09G - Edition 07.2014
184 Rep. gr.38 - Gears, control
