2.9 Removing and installing selector mech‐
anism
⇒ “2.9.1 Removing and installing shift mechanism Fabia II, Room‐
ster, Rapid”, page 74
⇒ “2.9.2 Removing and installing slave cylinder Octavia II, Superb
II”, page 80
⇒ “2.9.3 Remove and install shift mechanism Octavia IlI”,
page 84
⇒ “2.9.4 Removing and installing shift mechanism (Yeti)”,
page 88
2.9.1 Removing and installing shift mecha‐
nism Fabia II, Roomster, Rapid
Removing
– Shift selector lever into position “P”.
– Switch off ignition.
WARNING
Observe measures when disconnecting and connecting the
battery ⇒ Electrical System; Rep. gr. 27 .
– Disconnect the battery-earth strap with the ignition off ⇒ Elec‐
trical System; Rep. gr. 27 .
Note
If the battery earth strap is disconnected and connected, carry out
additional operations ⇒ Electrical System; Rep. gr. 27 .
– Removing the selector lever handle and cover for the shift
mechanism:
♦ ⇒ “2.6 Removing and installing and installing selector lever
handle up to 10.2012”, page 65 .
♦ ⇒ “2.7 Removing and installing selector lever handle as of
11.2012”, page 70 .
– Remove ashtray or storage area in front of the shift mecha‐
nism ⇒ Body Work; Rep. gr. 68 .
– Remove the centre console ⇒ Body Work; Rep. gr. 68 .
– Remove engine cover ⇒ engine; Rep. gr. 10 .
– Disconnect plug from automatic gearbox control unit -J217-
⇒ “1.2.2 Removing and installing automatic gearbox control
unit J217 (Fabia II, Roomster, Rapid)”, page 38 .
– Remove battery and battery tray ⇒ Electrical System; Rep.
gr. 27 .
– Remove intake hose ⇒ Engine; Rep. gr. 24 .
Fabia II 2007 ➤ , Fabia II 2009 ➤ , Fabia II 2011 ➤ , Octavia II 2004 ➤ ...
Gearbox 09G - Edition 07.2014
74 Rep. gr.37 - Controls, housing
