Sony PMW-EX3 User Manual

Setup Menu List
11
8
Menu Configuration and Detailed Settings
2)Valid only when the RM-B750/B150 Remote Control
Unit is connected
3)If the mouted lens does not have Auto Iris function,
only the gain and shutter are adjusted automatically.
AUDIO SET Menu
AUDIO SET
Menu items Subitems and setting values Contents
Audio Input
Setting for audio
inputs
TRIM CH-1
–11 dBu to –65 dBu (–41 dBu)
Finely adjust the sensitivity of channel 1 of external
microphone input in steps of 6 dB.
TRIM CH-2
–11 dBu to –65 dBu (–41 dBu)
Finely adjust the sensitivity of channel 2 of external
microphone input in steps of 6 dB.
AGC Link
Linked / Separated
Select the gain link condition when the audio level adjustment
is in AGC mode.
Linked: To vary the CH-1 gain and the CH-2 gain in
synchronization.
Separated: To vary the CH-1 gain and the CH-2 gain
independently according to the respective levels.
1KHz Tone
On / Off
Turn the 1-kHz reference tone signal on/off.
Wind Filter CH-1
On / Off
Turn the wind filter for channel 1 on/off.
Wind Filter CH-2
On / Off
Turn the wind filter for channel 2 on/off.
EXT CH Select
CH-1
CH-1/CH-2
CH-1: To record channel 1 audio input on both channels 1
and 2.
CH-1/CH-2: To record channel 1 and channel 2 inputs on the
respective channels.
Audio Output
Setting for audio
outputs
Monitor CH
CH-1/CH-2 (CH-3/CH-4)
CH-1+CH-2 (CH-3+CH-4)
CH-1 (CH-3)
CH-2 (CH-4)
Select the audio channel(s) to be fed to the headphones and
the built-in speaker.
CH-1/CH-2 (CH-3/CH-4): Stereo
CH-1+CH-2 (CH-3+CH-4): Mix
CH-1 (CH-3): CH-1 (CH-3) only
CH-2 (CH-4): CH-2 (CH-4) only
( ): with Output CH set to “CH-3/CH-4”
Output CH
CH-1/CH-2
CH-3/CH-4
Select audio output channels from either channels 1 and 2 or
channels 3 and 4.
Alarm Level
0 to 10 (5)
Set the alarm sound volume.
Beep
On / Off
Select whether or not to sound a beep upon each operation.

Sony PMW-EX3 Specifications

General

Digital zoom	0 x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Sensor type	CMOS
Total megapixels	0 MP
Optical sensor size	1/2 \
Display diagonal	3.5 \
Interface	USB
Resolution	1920 x 1080 pixels
Expansion slots	ExpressCard/34 (x 2)
Power requirements	DC 12V
Power consumption (typical)	13.5 W
Camera shutter speed	1/33 - 1/2000 s
Minimum illumination	0.14 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum memory card size	32 GB
Product color	Black
Battery type	BP-U30/BP-U60
Battery life (max)	- h
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	400 mm
Width	250 mm
Height	210 mm
Weight	1900 g
