Sony PMW-EX3 User Manual

Backup Battery
14
4
Appendixes
8 Select “Store” and specify the file in
which you wish to store the data.
9 When the confirmation message is
displayed, select “Execute.”
If the lens is a serial lens, the corresponding lens
file is automatically retrieved when you next
mount the lens, as long as “Auto Recall” is set to
“On.”
If the lens is a non-serial lens or if “Auto Recall”
is set to “Off,” retrieve the corresponding file
with a menu operation (Recall) when you next
mount the lens.
To change the file name
The initial file names (User_File1 to User_File4)
can be changed with “File ID” of the menu (up to
16 characters).
To clear the compensation data
The compensation data of the current lens file can
be cleared to the factory-set values by selecting
“No Offset” from the menu.
For details on menu operations, see “Basic Menu
Operations” on page 111.
This camcorder uses a backup battery to retain
various setting data.
A lithium battery (CR2032) for backup is
mounted in the camcorder at the factory.
The backup battery retains the date, time, and
timecode in Free Run mode even when no
operating power is being supplied.
Service life of the backup battery
When the backup battery’s voltage falls, the
backup battery low-voltage warning appears in
the viewfinder.
If this warning appears, replace the battery as
soon as possible.
Battery may explode if mistreated.
Do not recharge, disassemble, or dispose of in
fire.
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type recommended by the
manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Replacing the backup battery
Notes
• Be sure to set the power switch to OFF when
replacing the backup battery.
• Be careful not to drop the removed screw into
the camcorder.
1 Open the cover of the backup battery
holder on the bottom by loosening the
screw, and remove the battery.
00:00
A uto FB ADJ
File
Fla r e
S hading : U1: U ser_Fi le 1
: O n
LENS
Lens I D
R ecal l
S tore
File I D
N o O ffset
A uto R ecal l
B
B
B
YH 1 2 x 4 . 8 I RS
B
B
00:00
A uto FB ADJ
File
Fla r e
S hading
VC L - 6 1 4 B 2 X
XS 8 X4AS - XB 8
U ser_Fi le 1
U ser_Fi le 2
U ser_Fi le 3
U ser_Fi le 4
:
:
LENS
Lens I D
R
ecal l
S tore
File I D
N
o O ffset
A uto R ecal l
B
B
B
B
B
Backup Battery
WARNING
CAUTION

Sony PMW-EX3 Specifications

General

Digital zoom	0 x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Sensor type	CMOS
Total megapixels	0 MP
Optical sensor size	1/2 \
Display diagonal	3.5 \
Interface	USB
Resolution	1920 x 1080 pixels
Expansion slots	ExpressCard/34 (x 2)
Power requirements	DC 12V
Power consumption (typical)	13.5 W
Camera shutter speed	1/33 - 1/2000 s
Minimum illumination	0.14 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum memory card size	32 GB
Product color	Black
Battery type	BP-U30/BP-U60
Battery life (max)	- h
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	400 mm
Width	250 mm
Height	210 mm
Weight	1900 g
