Sony PMW-EX3 User Manual

Setup Menu List
119
Menu Configuration and Detailed Settings
VIDEO SET Menu
VIDEO SET
Menu items Setting values Contents
YPbPr/SDI Out
Select
Setting the
component/SDI
outputs
HD / SD/ Off Select the output signal from the COMPONENT OUT
connector and the SDI OUT connector.
HD: To output the same HD signal as that in recording and
playback
SD: To output a down-converted SD signal
Off: No output
YPbPr/SDI Out
Display
Setting the
character
information for the
component/SDI
outputs
On / Off Set whether to add the same menus and status indications as
those in the viewfinder to the output signals from the
COMPONENT OUT connector and the SDI OUT connector.
Video Out
Display
Setting the
character
information for the
composite output
On / Off Set whether to add the same menus and status indications as
those in the viewfinder to the output signal from the
MONITOR OUT and S VIDEO connectors.
Note
On the thumbnail, EXPAND CLIP and SHOTMARK screens,
the same menus and status indications as those in the
viewfinder are displayed regardless of the setting of this item.
Setup
Setting 7.5% setup
for the composite
signal
On / Off
Set whether to add 7.5% setup to the output signal from the
MONITOR OUT and S VIDEO connectors when a format of
NTSC is selected (Invalid when a format of PAL is selected).
Note
The default setting is different among the sales areas.
United States and Canada: On
Other areas: Off
Down
Converter
Selecting the
operation mode of
the down converter
Squeeze / Letterbox / Edge
Crop
Set the output mode (aspect) for SD output from the
MONITOR OUT, S VIDEO, COMPONENT OUT, and SDI
OUT connectors.
Squeeze: To horizontally reduce a 16:9 picture to output a 4:3
Letterbox: To mask the upper and lower areas of a 4:3 picture
to display a 16:9 picture in the center of the screen
Edge Crop: To cut the both sides of a 16:9 picture to output a
4:3 picture

Sony PMW-EX3 Specifications

General

Digital zoom	0 x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Sensor type	CMOS
Total megapixels	0 MP
Optical sensor size	1/2 \
Display diagonal	3.5 \
Interface	USB
Resolution	1920 x 1080 pixels
Expansion slots	ExpressCard/34 (x 2)
Power requirements	DC 12V
Power consumption (typical)	13.5 W
Camera shutter speed	1/33 - 1/2000 s
Minimum illumination	0.14 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum memory card size	32 GB
Product color	Black
Battery type	BP-U30/BP-U60
Battery life (max)	- h
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	400 mm
Width	250 mm
Height	210 mm
Weight	1900 g
