Sony PMW-EX3 User Manual

Setup Menu List
12
0
Menu Configuration and Detailed Settings
VF SET Menu
VF SET
Menu items Subitems and setting values Contents
VF
Setting the
viewfinder
Color
–99 to +99 (±0)
Adjust the color of pictures in the viewfinder.
Mode
Color / B&W
Select the display mode of the viewfinder.
Color: Color mode
B&W: Monochrome mode
Peaking
Setting the peaking
function for the
viewfinder
Type
Normal / Color
Select the circuit to be used for the peaking function.
Normal: To use the VF DETAIL circuit of the viewfinder
Color: To use the peaking circuit of the camcorder
Color
White / Red / Yellow / Blue
When you select “Color” for “Type,” select the color of the
peaking signal.
Frequency
Normal / High
When you select “Nornal” for “Type,” select the frequency to
be detected by the VF DETAIL circuit.
Marker
Setting the
markers added to
pictures in the
viewfinder
Setting
On / Off
Turn all marker indications on/off in combination.
Safety Zone
On / Off
Turn the safety marker on/off.
Safety Area
80% / 90% / 92.5% / 95%
Select the size (ratio to the entire screen) of the safety zone
marker.
Center Marker
On / Off
Turn the center marker on/off.
Aspect Marker
On / Off
Turn the aspect marker on/off.
Aspect Select
4:3 / 13:9 / 14:9 / 15:9
Select the type of the aspect marker.
Guide Frame
On / Off
Turn the guide frame marker on/off.
Zebra
Setting the zebra
pattern
Zebra Select
1 / 2 / Both
Select the zebra pattern(s) to be displayed.
1: To display zebra 1 only
2: To display zebra 2 only
Both: To display both zebra 1 and zebra 2
Zebra1 Level
50 to 107 (70)
Set the display level of zebra 1.

Sony PMW-EX3 Specifications

General

Digital zoom	0 x
Optical zoom	14 x
Image stabilizer	Yes
Focal length range	5.8 - 81.2 mm
Focal length (35mm film equivalent)	31.4 - 439 mm
Sensor type	CMOS
Total megapixels	0 MP
Optical sensor size	1/2 \
Display diagonal	3.5 \
Interface	USB
Resolution	1920 x 1080 pixels
Expansion slots	ExpressCard/34 (x 2)
Power requirements	DC 12V
Power consumption (typical)	13.5 W
Camera shutter speed	1/33 - 1/2000 s
Minimum illumination	0.14 lx
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum memory card size	32 GB
Product color	Black
Battery type	BP-U30/BP-U60
Battery life (max)	- h
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	400 mm
Width	250 mm
Height	210 mm
Weight	1900 g
