1. GENERAL INFORMATION/TROUBLE DIAGNOSIS
1-6
SPECIFICATIONS
MAKER SANYANG MODEL JD05W/JE05W
Overall Length 1900 mm Front TELESCOPIC FORK
Overall Width 655 mm
Suspen
sion
System
Rear UNIT SWING
Overall Height 1140 mm Front 120/60-13
DIMENSION
Wheel Base 1300 mm
Tire
Specifi
cations
Rear 130/70-12
Front 43.5 kg
Rear 69.5 kg
Front DISK (ø 226 mm)
Curb Weight
Total 113kg
Brake
System
Rear DRUM (ø 110 mm)
Passengers/
Weight
Two men/188 kg Max. Speed 45 km/hr
Front 72kg
Performa
nce
Climb Ability 18° Below
Rear 116 kg Primary Reduction Belt,3.00～1.0
WEIGHT
Total Weight
Total 263kg
Secondary
Reduction
GEAR
Type 2-STROKE ENGINE Clutch Auto Centrifugal clutch
Installation and
arrangement
Vertical, below center,
incline 80°
Deceleration
equipment
Transmission C.V.T
Fuel Used Unleaded (93/95) Speedometer 0 ~ 80 km/hr
Cycle/Cooling
4-stroke/forced air
cooled
Horn 80~112 dB/A
Bore 39 mm Muffler Expansion & Pulse Type
Stroke 41.4 mm
Exhaust Pipe Position
and Direction
Right side, and
Backward
Cylinder
Number/Arran
gement
Single Cylinder Lubrication System
forced circulation &
splashing
Displacement 49.4 cc CO(g/km) 1.057
Compression
Ratio
7.2±0.2 : 1
Exhaust
Emission
(IDLE)
HC(g/km) 0.149
Idle speed
1900±100 rpm
Fuel tank capacity
5.20L
Max. HP 2.5KW/ 6000 rpm
Air Filtration
Paper filter
Max. Torque 4.1N.m /5000 rpm Noise Emission < 84dB(A)
Ignition C.D.I.
ENGINE
Starting System Electrical & Kick starter
