14. Rear Wheel / Rear Cushion
14-2
Maintenance Information
Specification
Item Standard value (mm)
Rear wheel rim run out —
Torque Value
Rear cushion upper mounting bolt 3.5~4.5kgf-m
Rear cushion lower mounting bolt 2.4~3.0kgf-m
Rear wheel nut 11.0~13.0kgf-m
Bolts for the brake disc 2.4~3.0kgf-m
Exhaust pipe connection nut 1.0~1.4kgf-m
Exhaust muffler mounting bolt 2.4~3.0kgf-m
Troubleshooting
Rear wheel wobbling
1. Bend wheel rim
2. Poor tire
3. Loosen wheel shaft
Cushion too soft
1. Insufficient cushion spring force
Poor brake performance
1. Poor brake adjustment
2. Contaminated brake lining
3. Worn brake lining cam
4. Worn brake cam lever
5. Worn brake drum
6. Improper installation of brake arm gear set.
