1. GENERAL INFORMATION/TROUBLE DIAGNOSIS
1-7
TORQUE VALUES (ENGINE)
ITEM Q'TY
THREAD DIA
(mm)
TORQUE
VALUE(Kg-m)
REMARKS
Cylinder head bolts 4 7 1.6~2.0 Tighten to head
Crankcase flange bolt 7 6 0.8~1.2
Mission case flange bolt 7 8 2.4~3.0
Mission oil refilling bolt 1 8 1.0~1.5
Mission oil draining plug 1 10 1.0~1.5
Spark plug 1 10 1.1~1.7
Start motor flange bolt 2 6 0.8~1.2
Stator flange bolt 2 6 0.8~1.2
Pulse generator flange bolt 2 6 0.8~1.2
Flywheel nut 1 10 3.5~4.5
Inlet pipe flange bolt 4 6 0.8~1.2
Oil pump set plate flange bolt 1 6 0.8~1.2
Cooling fan flange bolt 4 6 0.8~1.2
Fan cover flange bolt 3 6 0.8~1.2
Carburetor insulated joint flange bolt 2 6 0.8~1.2
Shroud 1 6 0.8~1.2
Movable drive face nut 1 12 3.5~4.5
Driven pulley plate nut 1 10 5.5~6.5
L.crankcase cover flange bolt 10 6 0.8~1.2
Rear brake shoe anchor pin flange nut
1 8 1.5~2.0
Rear brake arm flange bolt 1 6 0.8~1.2
Kick starter arm bolt 1 6 0.8~1.2
Exhaust pipe bolts 3 8 2.4~3.0
Exhaust pipe connecting nuts 2 6 0.8~1.2
