9. Final Driving Mechanism
9-7
Bearing Replacement
Remove gearbox bearing from left crankcase and
gearbox cover using following tools.
Caution
Never install used bearings. Once bearing
removed, it has to be replaced with new one.
Install new bearings into left crankcase.
Install new bearings into gearbox cover.
Special tool: Bearing driver
Apply with grease onto final shaft oil seal.
Install the oil seal into gearbox cover.
Special tool:Oil seal driver
Special tool
Special tool
Oil seal driver
Oil seal
Special tool
To Next Page
