Sym JD05W User Manual

11. BODY COVER
11-1
MAINTENANCE INFORMATION ...... 11-2
HANDLE COVER............................... 11-3
FRONT COVER................................. 11-4
FRONT INNER BOX.......................... 11-5
BODY COVER/REAR CENTER
COVER/REAR FENDER ....................11-6
FRONT CENTER COVER.................. 11-8
LUGGAGE BOX................................. 11-8
FLOOR PANEL.................................. 11-8
SIDE COVER ..................................... 11-9
UNDER COVER................................. 11-10
Handle visor
Handle front
Top cover
Inner box
Front cover
Under spoiler
Front fender
Right side cover
Left side cover
Floor panel
Under cover
Inner box cover
Center cover
Battery cover
Right body cover
Left bod
y
cover
Rear carrier
Inner fender
Rear mudguard
Rear fender
Rear fender
mudguard
Splash board plate
Rear handle cover
R .rear mirror
L .rear mirror
