GTS Technical Manual
5. March 2013 Edition: V1.10/2013 4-3
Copyright © 2013, Diversey Inc.
04.1 swingo 455B - technical data_V1.00.fm
4.2.3 Dimensions and weights
Picture 1: Dimensions
Pos. Unit Value
Dimensions without squeegee L/W/H (mm) 1100/480/920
Door pass through with (without squeegee) (mm) 690 (489)
Battery compartment L/W/H (mm) 350/319/200
Net weight (without batteries, empty tank) (kg) 58
Weight, ready to use with 50 Ah batteries (kg) 120
Weight, ready for shipping (kg) 62
Max. floor pressure front (N/mm2) 0.96
Max. floor pressure rear (N/mm2) 0.22
Turning radius (between two walls) (mm) 1050
Wheel diameter front (mm) 200
Wheel diameter rear (mm) 100
Table 4: Dimensions and weights
