GTS Technical Manual
5. March 2013 Edition: V1.10/2013 6-4
Copyright © 2013, Diversey Inc.
06.14.11 dashboard - 455B_V1.00.fm
6.2 Dashboard
6.2.2 Mounting of dashboard
Picture 2: Dashboard
• Clean the surface where the dashboard will be placed.
• Position the new dashboard foil.
• Complete assembling according to the chapter REMOVING OF
HANDLE COVER AND ELECTRONICS.
Ensure that the loop of the ribbon cable is positioned correctly and
does not touch the switch levers.
