GTS Technical Manual
5. March 2013 Edition: V1.10/2013 4-5
Copyright © 2013, Diversey Inc.
04.1 swingo 455B - technical data_V1.00.fm
4.4 Charger
4.5 Brush system
Pos. Unit Value
Primary (V) 230-240
Primary (Hz) 50-60
Secondary (V) 24
Secondary (A) 9
Protection type IP30
Approval UL/CE
Cable length/BMS cable (m) 3
Table 7: Charger
Pos. Unit Value
Brush system (mm) 430
Brush motor (W) 750
Brush speed (rpm) 130
Brush pressure (kg) 32
Brush pressure min. - max. (N/cm2) 0.22
Brush pressure min. - max. (g/cm2) 22
Table 8: Brush system
