GTS Technical Manual
5. March 2013 Edition: V1.10/2013 5-25
Copyright © 2013, Diversey Inc.
05.16.21 vacuum unit , water outlet - regulation set - 455B_455E_V1.00.fm
5.3 Vacuum unit, water outlet
5.3.4 Mounting of water regulation set
Picture 31: Water regulation set
• Mount new water regulation set.
The diameter of the water outlet on the tank shrinks as soon the outlet
stub or water regulation set is removed.
Replace the outlet stub immediately with the water regulation set.
• Position new water regulation set fixation screw.
• Connect fresh water hose to the water regulation set.
• Position clamp on fresh water draining hose.
• Position fresh water draining hose on the water regulation set.
• Tighten the fresh water draining hose clamp.
